Brass Reducing Nipple Male x Female BSPP

Brass Threaded Fittings suitable for a wide range of applications.

High quality finishing and machining.
BSPP Threaded ends according to ISO 228-1 standard.

End Connections

Male x Female BSPP
Working Pressure

16 Bar
Material

Brass
Sizes Available

1/4″ x 1/8″ – 2″ x 11/2″
Specification

Suitable for use with potable water.
4MS Compliant

Available options

Part No	Size	Description
1247-1/4×1/8	1/4×1/8	1247 RED.SOCKETM>F 1/4″X1/8″
1247-3/8×1/8	3/8×1/8	1247 RED.SOCKETM>F 3/8″X1/8″
1247-3/8×1/4	3/8×1/4	1247 RED.SOCKETM>F 3/8″X1/4″
1247-1/2×1/4	1/2×1/4	1247 RED.SOCKETM>F 1/2″X1/4″
1247-1/2×3/8	1/2×3/8	1247 RED.SOCKETM>F 1/2″X3/8″
1247-3/4×1/4	3/4×1/4	1247 RED.SOCKETM>F 3/4″X1/4″
1247-3/4×3/8	3/4×3/8	1247 RED.SOCKETM>F 3/4″X3/8″
1247-3/4×1/2	3/4×1/2	1247 RED.SOCKETM>F 3/4″X1/2″
1247-1×1/2	1×1/2	1247 RED.SOCKETM>F 1″X1/2″
1247-1×3/4	1×3/4	1247 RED.SOCKETM>F 1″X3/4″
1247-11/4×3/4	1 1/4×3/4	1247 RED.SOCKETM>F 1″1/4X3/4″
1247-11/4×1	1 1/4×1	1247 RED.SOCKETM>F 1″1/4X1″
1247-11/2×1	1 1/2×1	1247 RED.SOCKETM>F 1″1/2×1″
1247-11/2×11/4	1 1/2×1 1/4	1247 RED.SOCKETM>F 1″1/2X1″1/4
1247-2×11/4	2×1 1/4	1247 RED.SOCKETM>F 2″X1″1/4
1247-2×11/2	2×1 1/2	1247 RED.SOCKETM>F 2″X1″1/2
