Hexagon Reducing Nipple, Male BSPT, 316 SS

150LB BSP Threaded Fittings
Stainless Steel – CF8M (316)

General purpose Stainless Steel 316 corrosion resistant 150lb Class Fittings.

Female threads are BSPP (Parallel) to ISO 228-1.
Male Threads are BSPT (Taper) to ISO 7-1.

End Connections

Male BSPT
Working Pressure

1/8″ – 2″ 16 Bar
2 1/2″ – 4″ 12 Bar
Material

Stainless Steel 316
Sizes Available

1/8″ – 4″

Available options

Part No	Size	Description
SSHRN1/4X1/8	1/4″x1/8″	Hex Red Nipples Male/Male BSPT
SSHRN3/8X1/8	3/8″x1/8″	Hex Red Nipples Male/Male BSPT
SSHRN3/8X1/4	3/8″x1/4″	Hex Red Nipples Male/Male BSPT
SSHRN1/2X1/8	1/2″x1/8″	Hex Red Nipples Male/Male BSPT
SSHRN1/2X1/4	1/2″x1/4″	Hex Red Nipples Male/Male BSPT
SSHRN1/2X3/8	1/2″x3/8″	Hex Red Nipples Male/Male BSPT
SSHRN3/4X1/4	3/4″x1/4″	Hex Red Nipples Male/Male BSPT
SSHRN3/4X3/8	3/4″x3/8″	Hex Red Nipples Male/Male BSPT
SSHRN3/4X1/2	3/4″x1/2″	Hex Red Nipples Male/Male BSPT
SSHRN1X1/4	1″x1/4″	Hex Red Nipples Male/Male BSPT
SSHRN1X3/8	1″x3/8″	Hex Red Nipples Male/Male BSPT
SSHRN1X1/2	1″x1/2″	Hex Red Nipples Male/Male BSPT
SSHRN1X3/4	1″x3/4″	Hex Red Nipples Male/Male BSPT
SSHRN1 1/4X1/2	1 1/4″x 1/2″	Hex Red Nipples Male/Male BSPT
SSHRN1 1/4X3/4	1 1/4″x 3/4″	Hex Red Nipples Male/Male BSPT
SSHRN1 1/4X1	1 1/4″x1″	Hex Red Nipples Male/Male BSPT
SSHRN1 1/2X1/2	1 1/2″x1/2″	Hex Red Nipples Male/Male BSPT
SSHRN1 1/2X3/4	1 1/2″x3/4″	Hex Red Nipples Male/Male BSPT
SSHRN1 1/2X1	1 1/2″x1″	Hex Red Nipples Male/Male BSPT
SSHRN1 1/2X1 1/4	1 1/2″x1 1/4″	Hex Red Nipples Male/Male BSPT
SSHRN2X1/2	2″x 1/2″	Hex Red Nipples Male/Male BSPT
SSHRN2X3/4	2″x 3/4″	Hex Red Nipples Male/Male BSPT
SSHRN2X1	2″x 1″	Hex Red Nipples Male/Male BSPT
SSHRN2X11/4	2″x 1 1/4″	Hex Red Nipples Male/Male BSPT
SSHRN2X1 1/2	2″x1 1/2″	Hex Red Nipples Male/Male BSPT
SSHRN2 1/2X11/2	2 1/2″x11/2″	Hex Red Nipples Male/Male BSPT
SSHRN2 1/2X2	2 1/2″x2″	Hex Red Nipples Male/Male BSPT
SSHRN3X2	3″x2″	Hex Red Nipples Male/Male BSPT
SSHRN3X21/2	3″x2 1/2″	Hex Red Nipples Male/Male BSPT
SSHRN4X2	4″x2″	Hex Red Nipples Male/Male BSPT
SSHRN4X3	4″x3″	Hex Red Nipples Male/Male BSPT
