Industrial Valves by Orseal

Hosetail Adapter, Male BSPT, 316 SS

150LB BSP Threaded Fittings
Stainless Steel – CF8M (316)

General purpose Stainless Steel 316 corrosion resistant 150lb Class Fittings.

Female threads are BSPP (Parallel) to ISO 228-1.
Male Threads are BSPT (Taper) to ISO 7-1.

  • End Connections
    Male BSPT
  • Working Pressure
    1/8″ – 2″ 16 Bar
    2 1/2″ – 4″ 12 Bar
  • Material
    Stainless Steel 316
  • Sizes Available
    1/8″ – 4″

Available options

Part No
Size
Description
SSHTM-6X1/41/4″ x 9mmHexagon Hose Tail BSPT
SSHTM-9.53X1/41/4″ x 9.53mmHexagon Hose Tail BSPT
SSHTM-10X3/83/8″ x 11mmHexagon Hose Tail BSPT
SSHTM-9.53X1/21/2″ BSP x 9.53mmHexagon Hose Tail BSPT
SSHTM-12X1/21/2″ x 13mmHexagon Hose Tail BSPT
SSHTM-20X1/21/2″ x 20mmHexagon Hose Tail BSPT
SSHTM-19X3/43/4″ x 20.5mmHexagon Hose Tail BSPT
SSHTM-25X11″ x 25mmHexagon Hose Tail BSPT
SSHTM-32X1 1/41 1/4″ x 33mmHexagon Hose Tail BSPT
SSHTM-38X1 1/21 1/2″ x 39mmHexagon Hose Tail BSPT
SSHTM-50X22″ x 52.5mmHexagon Hose Tail BSPT
SSHTM-63.5X21/22 1/2″ x 63.5mmHexagon Hose Tail BSPT
SSHTM-76.2X33″ x 76.2mmHexagon Hose Tail BSPT
SSHTM-101.6X44″ x 101.6mmHexagon Hose Tail BSPT
Enquire now for pricing
