Angled, T Handle, Ball Valve. Gas Approved En:331.


1074 Series T Handle, Brass Nickel Plated Angled Ball Valve Female BSPP x Male BSPT

Full bore ball valve for fuel gas, heavy series.
Made in Italy.

  • End Connections

    F BSPP EN 10226 x M BSPT

  • Working Pressure
    Fuel Gas 5 MOP
    Other uses PN 50 up to 1/2″ and PN 16 up to 4″
  • Temperature
    Fuel Gas – 20°c to +60°c
    Other uses -20°c to +130°c
  • Body
    Forged Nickel Plated Brass
  • Seals
    PTFE
  • Approvals
    EN: 331
  • Sizes Available

    1/2″, 3/4″, 1″

Available options

Part No
Size
Description
Unit Price
1074-C 1/2” ANGLED FM FULL BORE BSPP £5.38
1074-E 3/4” ANGLED FM FULL BORE BSPP £8.26
1074-F 1” ANGLED FM FULL BORE BSPP £12.00
