Itap 130 Brass Swing Check Valve

Brass Swing Check Valve. Itap series 130. Brass body with NBR seal.

Suitable for domestic water services, heating and air conditioning plants, compressed air systems.
They can be installed in any position: vertical, horizontal, oblique.
Suitable for use with gasoline and fuels in general.
Made in Italy.

  • End Connections
    F x F ISO228
  • Working Pressure

    25 Bar up to 1″
    18 Bar 1 1/4″ to 2″
    8 Bar 21/2″ to 4″

  • Temperature
    -20°c – + 100°c (with water)
    150°c with fluid hydrocarbons or compressed air
  • Body
    Brass
  • Seals

    NBR

  • Spring
    Stainless Steel
  • Sizes Available

    3/8″ – 4″

Available options

Part No
Size
Seat
Description
300PS-B 3/8″ NBR BSP SWING CHECK VALVE BR
300PS-C 1/2″ NBR BSP SWING CHECK VALVE BR
300PS-E 3/4″ NBR BSP SWING CHECK VALVE BR
300PS-F 1″ NBR BSP SWING CHECK VALVE BR
300PS-G 1 1/4″ NBR BSP SWING CHECK VALVE BR
300PS-H 1 1/2″ NBR BSP SWING CHECK VALVE BR
300PS-J 2″ NBR BSP SWING CHECK VALVE BR
300PS-K 2 1/2″ Metal BSP SWING CHECK VALVE BR
300PS-L 3″ Metal BSP SWING CHECK VALVE BR
300PS-M 4″ Metal BSP SWING CHECK VALVE BR
