3 Way Brass Ball Valve T Port

Suitable for domestic water services, heating and air conditioning plants and compressed air systems.

End Connections

F x F ISO228
Working Pressure

1/4″ -3/4″ 50 Bar
1″ 45 Bar
11/4″ to 2″ 35 Bar
Temperature

-10°c to +120°c in absence of steam
Body

Brass Nickel Plated
Lever

Aluminium
Sizes Available

1/4″ – 2″

Available options

Part No	Size	Description
600PT-A	1/4″	BSP 3 WAY L PORT BALL VALVE
600PT-B	3/8″	BSP 3 WAY L PORT BALL VALVE
600PT-C	1/2″	BSP 3 WAY L PORT BALL VALVE
600PT-E	3/4″	BSP 3 WAY L PORT BALL VALVE
600PT-F	1″	BSP 3 WAY L PORT BALL VALVE
600PT-G	1 1/4″	BSP 3 WAY L PORT BALL VALVE
600PT-H	1 1/2″	BSP 3 WAY L PORT BALL VALVE
600PT-J	2″	BSP 3 WAY L PORT BALL VALVE
