Industrial Valves by Orseal

Itap 100 Brass Spring Check Valve

Brass Spring Check Valve. Itap Europa, 100 Series. Brass Body with Stainless Steel Spring.

Suitable for domestic water services, heating and air conditioning plants, compressed air systems.
They can be installed in any position: vertical, horizontal, oblique.
Made in Italy.

  • End Connections
    F x F ISO228
  • Working Pressure

    25 Bar up to 1″
    18 Bar 1 1/4″ to 2″
    12 Bar 21/2″ to 4″

  • Temperature
    -20°c – +100°c
  • Body
    Brass
  • Seals
    NBR
  • Spring
    Stainless Steel
  • Sizes Available
    1/4″ – 4″

Available options

Part No
Size
Description
3085SPC-B 3/8″ BSP SPRING CHECK VALVE BR
3085SPC-C 1/2″ BSP SPRING CHECK VALVE BR
3085SPC-E 3/4″ BSP SPRING CHECK VALVE BR
3085SPC-F 1″ BSP SPRING CHECK VALVE BR
3085SPC-G 1 1/4″ BSP SPRING CHECK VALVE BR
3085SPC-H 1 1/2″ BSP SPRING CHECK VALVE BR
3085SPC-J 2″ BSP SPRING CHECK VALVE BR
3085SPC-K 2 1/2″ BSP SPRING CHECK VALVE BR
3085SPC-L 3″ BSP SPRING CHECK VALVE BR
3085SPC-N 4″ BSP SPRING CHECK VALVE BR
Enquire Now
