Brass Equal Tee Connector

Brass compression fittings for use with a wide range of tubes. 13000 Series conforms to UNI EN 1254 2:2000

For use in a wide range of applications.

The working pressures and working temperatures depend on which type of tube is used, for this reason the values must be determined in accordance with the tubes features.

  • End Connections
    Tube x Tube x Tube
  • Material
    Brass
  • Approvals
    REACH 1907/2006
    RoHS 2011/65/CE
    UNI EN 1254 2:2000
    PED 2014/68/UE
    Silicon Free
  • Sizes Available
    4mm – 22mm
  • Country of Origin
    Italy
  • Commodity / HS Code
    74122000

Available options

Part No
Size
Description
13200-T04 4mm BRASS EQUAL TEE CONNECTOR
13200-T06 6mm BRASS EQUAL TEE CONNECTOR
13200-T08 8mm BRASS EQUAL TEE CONNECTOR
13200-T10 10mm BRASS EQUAL TEE CONNECTOR
13200-T12 12mm BRASS EQUAL TEE CONNECTOR
13200-T14 14mm BRASS EQUAL TEE CONNECTOR
13200-T16 16mm BRASS EQUAL TEE CONNECTOR
13200-T18 18mm BRASS EQUAL TEE CONNECTOR
13200-T22 22mm BRASS EQUAL TEE CONNECTOR
Enquire now for pricing
