Brass Tee, Female Centre Leg BSPP (Parallel)

Brass compression fittings for use with a wide range of tubes. 13000 Series conforms to UNI EN 1254 2:2000

For use in a wide range of applications.

The working pressures and working temperatures depend on which type of tube is used, for this reason the values must be determined in accordance with the tubes features.

  • End Connections
    Tube x Female BSPP x Tube
  • Material
    Brass
  • Approvals
    REACH 1907/2006
    RoHS 2011/65/CE
    UNI EN 1254 2:2000
    PED 2014/68/UE
    Silicon Free
  • Sizes Available
    4mm x 1/8″ – 18mm x 3/4″
  • Country of Origin
    Italy
  • Commodity / HS Code
    74122000

Available options

Part No
Size
Description
13240-T04X 4mm – 1/8″ BRASS TEE FEMALE CENTRE LEG
13240-T06X 6mm -1 /8″ BRASS TEE FEMALE CENTRE LEG
13240-T06A 6mm – 1/4″ BRASS TEE FEMALE CENTRE LEG
13240-T08X 8mm -1 /8″ BRASS TEE FEMALE CENTRE LEG
13240-T08A 8mm – 1/4″ BRASS TEE FEMALE CENTRE LEG
13240-T10A 10mm – 1/4″ BRASS TEE FEMALE CENTRE LEG
13240-T10B 10mm – 3/8″ BRASS TEE FEMALE CENTRE LEG
13240-T10C 10mm – 1/2″ BRASS TEE FEMALE CENTRE LEG
13240-T12A 13mm – 1/4″ BRASS TEE FEMALE CENTRE LEG
13240-T12B 12mm – 3/8″ BRASS TEE FEMALE CENTRE LEG
13240-T12C 12mm – 1/2″ BRASS TEE FEMALE CENTRE LEG
13240-T14C 14mm – 1/2″ BRASS TEE FEMALE CENTRE LEG
13240-T15C 15mm – 1/2″ BRASS TEE FEMALE CENTRE LEG
13240-T16C 16mm – 1/2″ BRASS TEE FEMALE CENTRE LEG
13240-T18C 18mm – 1/2″ BRASS TEE FEMALE CENTRE LEG
13240-T18E 18mm-3/4″ BRASS TEE FEMALE CENTRE LEG
Enquire now for pricing
